Multimode OM3 100G QSFP28 Active Optical Cable Low Power 850nm For Data Center

Brand Name : Unifiber or OEM

Model Number : 100G QSFP28 OM3 AOC Cable

Certification : ROHS

Place of Origin : China

MOQ : 10

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 500pcs/day

Delivery Time : 3~5 days

Packaging Details : PE bag

Product : 100G QSFP28 OM3 AOC Cable

Data Rate : 100G

Wavelength : 850nm

Fiber : Multimode OM3

Power supply : 3.3V

Length : 1~70m

Application : Data Center

Contact Now

100G QSFP28 OM3 AOC Cable 1/3/5/7/10/15/20M Active Optical Cable

100G QSFP28 active optical cable is a high-performance, low-power, long-distance interconnection solution that supports100G.
100G QSFP is a combination of 4 full-duplex channels, each of which can transmit data at a rate of up to 25.78125GB/s, providing an aggregation rate of 100GB/s.


Features
Support 100GBASE-SR4/EDR application
Compliant to QSFP28 Electrical MSA SFF-8636
Rate of up to 25.78125Gbps per channel
+3.3V single power supply
Low power consumption
Operating case temp Commercial: 0° to +70 °
RoHS 6 compliant


Applications :
100GBASE-SR4 at 25.78125Gbps per lane
InfiniBand QDR, EDR
Servers, switches, storage and host card adap

Form Factor Rate(bps) Wave(nm) Length TX/RX Connector Temp(℃) Optical Mode
QSFP28 100G 850 1m VCSEL/PIN MTP/MPO 0~70 OM3
QSFP28 100G 850 2m VCSEL/PIN MTP/MPO 0~70 OM3
QSFP28 100G 850 3m VCSEL/PIN MTP/MPO 0~70 OM3
QSFP28 100G 850 4m VCSEL/PIN MTP/MPO 0~70 OM3
QSFP28 100G 850 5m VCSEL/PIN MTP/MPO 0~70 OM3
QSFP28 100G 850 6m VCSEL/PIN MTP/MPO 0~70 OM3
QSFP28 100G 850 7m VCSEL/PIN MTP/MPO 0~70 OM3
QSFP28 100G 850 8m VCSEL/PIN MTP/MPO 0~70 OM3
QSFP28 100G 850 9m VCSEL/PIN MTP/MPO 0~70 OM3
QSFP28 100G 850 10m VCSEL/PIN MTP/MPO 0~70 OM3
QSFP28 100G 850 30m VCSEL/PIN MTP/MPO 0~70 OM3
QSFP28 100G 850 40m VCSEL/PIN MTP/MPO 0~70 OM3
QSFP28 100G 850 60m VCSEL/PIN MTP/MPO 0~70 OM3
